TL-600-A Aluminium / PVC cutting machine

​

​

•  Ø600 mm diam  TCT blade saw included

• Miter turning table from  -22,5º  to +157,5º

• 4HP (3kW) Brake-motor

• 2x Pneumatic vertical clamps

• 2x pneumatic horizontal clamps

• Bimanual control to activate the blade raise

• Twin pressure (low-HI) system for clamping cylinders

• Adjustable backfence to increase cutting range

• Adjustable cutting speed

• Pneumatic lubrification system ( venturi )

• Policarbonate shield

​

​

OPTIONS:

• Motor 5,3HP (4kW)

• Motor 7,3HP (5,5 kW)

• Digital angle display by linear encoder

• Mist Lubrification LUBETOOLS with pump

• Automatic OPEN/CLOSE hood

• Laser line

• Conection with vacuum cleaner (ON/OFF)

• LED illumination

• Speed (RPM) inverter

​

​​​​​​​​

PACKAGING & DIMENSIONS:

• 1300 X 1220 X 1635 (500 Kg)

• Wooden crate

​
